"Urban Evader" Adjustable Carbine Buttstock: Laffs Dynamics

An adjustable buttstock for use on AR-15 buffer tube extensions. Compact in overall size; designed for use with short
barrel carbines. The buttstock toe is angled to allow for ease of transitioning from low ready, to shouldering the
weapon. Has a single 32mm long vertical sling loop. The latch lever has ridges down behind the pivot point for use
in wet environments.

This buttstock is designed for Milspec Carbine Buffer Tubes only.

Printer Used: Ender 3 V2

Filament Used: PLA+

Print Settings:

Extruder: 220C
Bed: 56C
First Layer Print Height: .20mm
Standard Layer Height: .2mm
Wall Perimeters: 6+
Infill: 25%+
Infill Pattern: Gyroid
Material Flow: 100%
Support Material Percentage: 16%

Hardware Needed:

1x Compression Spring 3/8in x 3/4in

1x M3x20 Set Screw / 3mm x 20mm Roll Pin

Accreditations:

ProSpaceDog: Created similar locking latch geometry from his adjustable buttstock design.
